protech QM1571 User Manual

RANGE RESOLUTION ACCURACY
40nF 10pF ±(5.0% reading + 7 digits)
400nF 0.1nF
±(3.0% reading + 5 digits)4µF 1nF
40µF 10nF
100µF 0.1µF ±(5.0% reading + 7 digits)
CAPACITANCE
Overload protection: 1000VDC or 1000VAC RMS
DUTY CYCLE
RANGE RESOLUTION ACCURACY
0.1~99.9% 0.1% ±(1.2% reading + 2 digits)
14
Pulse width: >100us, <100ms; Frequency width: 5Hz-150kHz.
RESISTANCE
Input protection: 1000VDC or 1000VAC RMS
RANGE RESOLUTION ACCURACY
400Ω 0.1Ω ±(0.8% reading + 5 digits)
4kΩ 1Ω
±(0.8% reading + 2 digits)40kΩ 10Ω
400kΩ 100Ω
4MΩ 1kΩ
±(2.5% reading + 8 digits)
40MΩ 10kΩ
