6 • SRT-2
Assembly the rear suspension / Montage van de achterste ophanging
Montierung von hintere Querlenker / Assemblage du train arrière
T0830.054
T58.023
T56.007
M3x14mm
T0830.040
T58.022
T0830.025
T0830.024
T0830.055
Nylstop M3
T63.029
T63.029
M3x14mm
T56.007
T0830.040
T58.022
T0830.025
T0830.055
T0830.024
Nylstop M3
T0830.054
T58.023
