Protect 800i C - Dip Switch Settings

PROTECT 800i C
TM
DIP Settings Fog Time Fog Volume
DIP 2 DIP 3 DIP 4 m³
OFF OFF OFF demo -
ON OFF OFF 20 sec 350
OFF ON OFF 40 sec 700
ON ON OFF 60 sec 850
OFF OFF ON 60 sec + 1 min. 1000
ON OFF ON 60 sec + 5 min. 1275
OFF ON ON 60s + 9 min. 1900
PROTECT 1500i C
TM
DIP Settings Fog Time Fog Volume
DIP 2 DIP 3 DIP 4 m³
OFF OFF OFF demo -
ON OFF OFF 20 sec 425
OFF ON OFF 40 sec 850
ON ON OFF 60 sec 1350
OFF OFF ON 80 sec 1600
ON OFF ON 80 sec + 4 min. 1950
OFF ON ON 80s + 9 min. 2740
Total time in max. pulse mode = 11 min.: 60 sec. + pulse shots.
Total fog production = 1900 m
3
.
Total capacity in the uid container = 3 complete sequence in pulse mode.
Total time in max. pulse mode = 10 min. and 20 sec.: 80 sec. + pulse shots.
Total fog production = 2740 m
3
.
Total capacity in the uid container = 3 complete sequence in pulse mode.
DIP switch settings
DIP
Function
1
Heat disable
On = The heating element disconnects
if disable is activated
2
Fog time
3
Fog time
4
Fog time
5
Arm*
6
Primary*
7
Secondary*
8
Fire-alarm delay**
9
Reserved. Leave in OFF position
10
Error indicator
On = Beeper connected
* ON = normal open
OFF = normal closed
** ON = delay is active
