Protect QUMULUS - DIP Switch Settings; DIP Switch Functions; Fog Time and Volume Configuration

PROTECT QUMULUS
®
DIP Settings Fog Time Fog Volume
DIP 2 DIP 3 DIP 4 m³
OFF OFF OFF Demo -
ON OFF OFF 20s 140
OFF ON OFF 40s 230
ON ON OFF 60s 400
OFF OFF ON 60s + 2 min. 600
ON OFF ON 60s + 4 min. 900
OFF ON ON - -
ON ON ON - -
DIP switch settings
DIP
Function
1
Heat disable
On = The heating element disconnects
if disable is activated
2
Fog time
3
Fog time
4
Fog time
5
Arm*
6
Primary*
7
Secondary*
8
Fire-alarm delay**
9
Reserved.
Leave in OFF position
10
Error indicator
On = Beeper connected
* ON = normal open
OFF = normal closed
** ON = delay is active
