Programming Procedure
This section is divided into two parts.
• Programming for an installation WITHOUT local wireless keys.
• Programming for an installation WITH local wireless keys.
Using the programming procedure WITH local wireless keys, is necessary only if you plan to use wireless keys
beyond the control panel’s capacity, or on a system that does not support 5800 Series wireless. Refer to the
6150RFPL2 Application Guidelines section for installations that require these settings.
Note: See the control panel's installation instructions for the acceptable keypad and receiver addresses.
If you are using a wireless key in High-Security mode (5804E) in the control panel, it will occupy one of the devices in the 6150RFPL2.
Programming for an Installation WITHOUT Local Wireless Keys
To program the 6150RFPL2 for an installation without any local wireless keys, perform the following steps:
Step
Action Display
1. Enter the Program mode by pressing the [1] and [3] keys
simultaneously for a few seconds within 30 seconds after applying
power or within 30 seconds after removing the case back.
Alternately flashes "oo" and two dashes.
2. Enter [1] (Keypad Address). Enter the 2-digit keypad address (01-31).
Press the [✻] key to continue.
Alternately flashes "cA" and the 2-digit keypad
address.
3. Enter [2] (Receiver Address). Enter the 2-digit receiver address (00-30).
Press the [✻] key to continue.
Alternately flashes “rA” and the 2-digit receiver
address.
4.
Enter [4] (House ID Source). Enter [1] (System) to use the House ID
programmed into the control panel, if RF keypad(s) and/or bi-
directional device(s):
• Are used on the control panel.
OR
• Neither is used.
Enter [0] (Local) to use the House ID programmed into the 6150RFPL2
(Program Address 3).
Note: If the House ID Source is:
• System (1), RF keypad and bi-directional units MUST match the
House ID programmed into the control panel.
• Local (0), RF keypad and bi-directional units MUST match the
House ID programmed into the 6150RFPL2.
Press the [✻] key to continue.
Alternately flashes “hS” and either "1" or "0."
5.
Enter [6] (Receiver Enable). Enter [1] to enable, or [0] to disable.
Enable the receiver if RF transmitters or wireless keypads are
programmed into the control.
Note: Make sure the number of receivers set for Enable (1) does not
exceed the capacity of the control panel.
Press the [✻] key to continue.
Alternately flashes “rE” and either "1" or "0."
6.
Enter [7] (Transmitter Module Enable). Enter [1] to enable, or [0] to
disable. Enter [1] if bi-directional devices are being used.
Note: If the House ID Source is System and more than one 6150RFPL2 is
used, make sure each of the keypads have the Transmitter Module
enabled. See Note under House ID Source step 4.
Press the [✻] key.
Alternately flashes “tE” and either "1" or "0."
Step
Action Display
7.
Enter [0] (High-Security Mode). To put the system into High-Security
mode, enter [1]. Enter [0] to disable.
En
8.
Press the [✻] key to exit the 6150RFPL2 Program mode.
“READY” or “NOT READY”
Note: This is all the 6150RFPL2 programming necessary for this application. Upon exiting the Program mode, the 6150RFPL2
alternately flashes "Ad," the 2-digit keypad address, and the 2-digit receiver address. If either of these is incorrect, repeat steps 1
through 3.
