INTRODUCTION
Connection Diagram
INTRODUCTION
Please read this entire operating manual completely and attentively before using this product, as it
covers a wide range of information on operating and safety. Or please do use this product in company
with a specialist!
Ventilation Fan
Temperature
Probe Socket
Temperature
Probe Socket
Contact-Less Key
Switch
LCD Screen
Output
Charging
Output Charging
LiPo/LiIon/LiFe
1~6 Cells
NiMH/NiCd
1~18 Cells
Lead Acid
2~24V
Universal
Balancing Port
Pitch=2.54mm
Universal
Balancing Port
Pitch=2.54mm
DC Input 11~18V
Input Power Source
Lead-Acid
DC 12V
AC Power Adapter
DC 11~18V 20A
USB Power Supply 5V/1A
PC Link Socket
USB Power
PC Link
