User Manual
9
Features
Feature Description
Digital Display 5,000 counts, 3-4/5 digit
Analog Bargraph display 25 segments
Backlight Automatically turns off after 1 minutes to save battery life
MIN MAX AVG Minimum, maximum and average reading memory
Manual or auto ranging In auto range, the meter selects the range with the best resolu-
tion for the present measurement value
Auto Power Off The meter shuts off automatically after 30 minutes if it is not
used.
Data Hold HOLD. Press this button to turn hold mode ON and OFF. When
the hold mode is activated, the meter beeps, freezes the display,
and displays the HOLD indicator on the LCD. HOLD mode freezes
the display for later view.
Range Hold RANGE. Use the RANGE button to manually select a range. Press
and hold RANGE button for two seconds to return the meter to
auto range mode. The meter is in auto range mode when the
AUTO indicator is on.
