Protek D705 User Manual

19
1000 V 1 V ± (0.8 % + 5 d) True RMS ± (1.0 % + 5 d) True RMS
DC 전류
범위 분해능 정확도
500 uA 0.1 μA ± (1.0 % + 3 d)
5000 uA 1 μA ± (1.0 % + 3 d)
50 mA 10 μA ± (1.0 % + 3 d)
400 mA 100 μA ± (1.0 % + 3 d)
5A 1 mA ± (1.0 % + 5 d)
10A 10 mA ± (1.0 % + 3 d)
AC 전류
범위 분해능
정확도
(45 Hz ~ 500 Hz) (500 Hz ~ 1 KHz)
500 uA 0.1 μA ± (0.8 % + 5 d) True RMS ± (2.0 % + 5 d) True RMS
5000 uA 1 μA ± (0.8 % + 5 d) True RMS ± (2.0 % + 5 d) True RMS
50 mA 10 μA ± (0.8 % + 5 d) True RMS ± (2.0 % + 5 d) True RMS
400 mA 100 μA ± (0.8 % + 5 d) True RMS ± (2.0 % + 5 d) True RMS

Protek D705 Specifications

General

Brand	Protek
Model	D705
Category	Multimeter
Language	English
