Protek D705 - Page 52

True-RMS Multimeter
20
5A 1 mA ± (1.5 % + 10 d) True
RMS
± (2.0 % + 10 d) True
RMS
10A 10 mA ± (0.8 % + 5 d) True RMS ± (2.0 % + 5 d) True RMS
Resistance
Range Resolution Accuracy
500 Ω 0.1 Ω ± (1.0 % + 5 d)
5 kΩ 0.001 kΩ ± (1.0 % + 5 d)
50 kΩ 0.01 kΩ ± (1.0 % + 5 d)
500 kΩ 0.1 kΩ ± (1.0 % + 5 d)
5 MΩ 0.001 MΩ ± (1.0 % + 5 d)
50 MΩ 0.01 MΩ ± (1.5 % + 10 d)
Continuity Test
Range Resolution Accuracy
500 Ω 0.1 Ω ± (1.0 % + 5 d)
Threshold Approx. 25 Ω
Response time 1 msec.
