Technical Notebook ..............................................................
Technical Training
General presentation of the open flue appliances.
All the models of the range have a common structure.
- The hydraulic unit (circulator rating, number of plates in the hot water heat exchanger, expansion tank capacity, etc)
- Control panel
The structure of open flue versions:
Draught diverter
Heat exchanger
Chambre de combustion
Hydraulic bloc
Gas valve
Electrical box
Smoke outlet
Over-ow safety device
Burner
Plate heat exchanger
Pump
360
450
Ø46
807
230
225
311
410
742
179
205
Ø125
311
410
Ø41
742
184
205
311
410
Ø36
742
158
175
(Ø43)
Gepard 23 MOV
Panther 25 KOV
Panther 12 / 25 KOO
