Protool CSP 145 E User Manual

10
Technical data
Operating controls & Description
Intended use
Cutting depth adjustable: for 90° 70 - 145 mm 95 - 165 mm
45° max. 110 mm max. 123 mm
60° max. 75 mm max.85mm
Mitre cutting angle adjustable 0° - 60° 0° - 60°
Saw blade outer diameter 380 mm 420 mm
center hole diameter 30 mm 30 mm
thickness 2,2 mm 2,5 mm
Riving knife thickness 2,5mm 2,8mm
Motor power:
rated input 2 600 W 2 800 W
output 1 500 W 1 700 W
No-load speed 3 100 min 3 100 min
Weight of the electric tool 22 kg 23,5 kg
Safety Class II / II /
-1 -1
GB
1. Guide plate
2. Main handle
3. Front handle
4. Lock-off button of the mains switch
5. Mains switch
6. Locking lever for cutting depth adjustment
(front)
7. Locking lever for cutting depth adjustment
(rear)
8. Cutting depth scale
9. Locking lever for cutting angle adjustment
(front)
10. Locking lever for cutting angle adjustment
(rear)
11. Cutting angle scale
12. Rip fence
13. Movable guard of the saw blade
14. Saw blade
15. Lever for movable guard opening
16. Overload indicator
17. Gauge mark
18. Guide rail (not included in the delivery)
19. Dust/chips extraction adapter
20. Spindle locking device
21. Blade fixing screw
22. Clamping flange
23. Riving knife
24. Screw for riving knife attachment
25. Hexagon key
The accessories shown or described in this
Operating Manual may not be included as a part
of delivery.
Particularly robust portable circular saw for
carpentry works, with large power reserves,
intended for sawing solid wood, glued boards
etc. in carpentry or woodworking in general, both
for workshop and site application.
For mitre cutting, crosscutting and straight rip
cutting.
The incorporated soft-start/brake electronic
circuit "SSB electronic" provides for soft starting
when the electric tool is switched on, as well as
short rundown time of approx. 5 s when the
electric tool is switched off.
The range of applications and operation modes
and may be extended by using the accessories
listed in this Operating Manual.
The user is solely liable for damage and
accidents caused by improper use of the
product.
For safe work with this electric tool and
prevention of injury, it is imperative to follow all
generally accepted safety principles and
regulations for prevention of accidents, and read
the enclosed "Safety instructions" thoroughly.
The manufacturer disclaims liability for damages
caused by unauthorized modifications or using
other than the supplied or specified accessories
with the electric tool.
Type reference CSP 145 E CSP 165 E

Protool CSP 145 E Specifications

General

Brand	Protool
Model	CSP 145 E
Category	Saw
Language	English
