Proview 770 - Page 6

Preset
Modes
VESA
800X600
VESA
1024X768
VESA
1024X768
VESA
1024X768
VESA
1280X1024
VESA
1280X1024
Pixel clock (MHz)
49.500 65.000 75.000 78.750 108.00 135.00
H-Frequency (KHz)
46.875 48.363 56.476 60.023 63.981 97.976
H-Total (µs)
21.333 20.677 17.707 16.660 15.630 12.540
H-Active Display (µs)
16.162 15.754 13.563 13.003 11.852 9.481
H-Blanking (µs)
5.172 4.923 4.053 3.657 3.778 3.022
Front Porch (µs)
0.323 0.369 0.320 0.203 0.444 0.119
H-Sync-width (µs)
1.616 2.092 1.813 1.219 1.037 1.067
H-Back Porch (µs)
3.232 2.462 1.920 2.235 2.296 1.837
V-Frequency (Hz)
75.0 60.0 70.1 75.0 60.0 75.0
V-Total (ms)
13.333 16.666 14.272 13.328 16.661 13.329
V-Active Display (ms)
12.800 15.880 13.599 12.795 16.005 12.804
V-Blanking (ms)
0.533 0.786 0.673 0.533 0.656 0.525
V-Front Porch (ms)
0.021 0.062 0.053 0.017 0.016 0.013
V-Sync-width (ms)
0.064 0.124 0.106 0.050 0.047 0.038
V-Back Porch (ms)
0.448 0.600 0.513 0.466 0.594 0.475
H/V Sync. Polarity
＋ ＋ － － － － ＋ ＋
＋ ＋ ＋ ＋
Interlace
NONE NONE NONE NONE NONE NONE
