Proview 770 - Replacement Parts List

H. REPLACEMENT PARTS LIST
770
NO Parts No. Description Part Location Q’ty
1
988-1L0-6001C
SH770
2 002-001-CEPOV-A CE Declaration 1
3 002-G01-FUJIT FUJITSU Warranty card 1
4 002-L03-FUJIT SH770 User’s Manual for FUJITSU 1
5 003-101-TCO9 All Series TCO99 Label for Carton 1
6 003-403-FUJIT SH770 Carton Label for FUJITSU 1
7 005-006-FUJIT SH770 Carton FUJITSU Logo 1
8 153-007-FUJIT SH770 Back Label FUJITSU Logo 1
9 170-000-0848C PE Bag 0.07MM 14x30.5cm 1
10 170-005-LCD7 LCD 17” PE Bag 1
11 170-005-VM541 PE Bag 300X200mm 1
12
826-000-SH770
SH770
13 003-002-0848-AM Carton Label 70x40mm 1
14 003-002-0848-A Carton Label 70x40mm 1
15 160-000-SH770L-A SH770 Polyfrom L EPS 1
16 160-000-SH770R-A SH770 Polyfrom R EPS 1
17 835-011-SH770 SH770 S7 Driver for FUJITSU 1
18 846-120-C3AL-SB Adapter 12V 40W 1
19
999-L01-SH770
SH770 TUV/TCO99
20 705-570-2603-3 AU 17" LCD Panel 170E3 1
21 849-40M-0770 Inverter for AU 1
22
899-00M-SH770
SH770 M/B MRT IC AU Panel
23 851-00M-SH770 SH770 M/B MRT IC AU DIP 1
24 152-000-SH570 TOSHIBA DC Jack Support NYLON. 1
25 232-R02-505T WR-C-5W 0.020ohm 5% TR1 1
26 330-100-16255 5mm EC 10uF 16V 105C M TP MI.
TC1,TC5,TC8,TC11,TC12,TC15,TC16,TC18,TC21,
TC24,TC25
11
27 330-101-16255 5mm EC 100uF 16V 105C M TP MI. TC10,TC7 2
28 330-220-16255 MINI CE 22uF/16V +-20% 105C TC17, 1
29 330-221-16255 EC H:5mm 220uF16V +-20% 105C TC2,TC3,TC6,TC9,TC13,TC19,TC20,TC26, 8
30 330-2R2-50275 E.CAP 2.2UF/50V +-20% 4*7 105C TC22, 1
31 330-470-16255 EC 47uF 16V 5*5 105C TC14,TC23 2
32 409-003-0110 DC Jack CN7, 1
33 409-003-0111 Red RCA Jack CN10, 1
34 409-003-0112 White RCA Jack CN9, 1
35 485-415-0005B DB15 (D-SUB) 15P Blue CN8, 1
36 504-000-6300L Reset IC V6300L TD92. TU1, 1
37 504-007-A431 KIA431/KEC TD3, 1
38 520-007-5822 IN5822(DIP) Shottky 30V/3A ZZ TD2, 1
39 531-110-49US 11.0592MHZ HC 49US Crystal Y1, 1
40 531-240-49US 24MHZ HC 49US Crystal 30PPM Y2, 1
41 630-002-1008 JWT A2001 PITCH 2.00mm 2P CN5,CN6, 2
