GB
PROXXON
-
MICROMOT
40
(E)
Dear customer,
Please read the enclosed safety regulations
and operating instructions carefully before
using the unit.
Safety regulations
Attention!
Please read and apply the following safety
regulations carefully before using the machine,
thereby protecting yourself and others.
-
Keep the working area clean and tidy.
-
D
O
not use electrical tools in rain, under wet
conditions
or
in the vicinity of inffammable
liquids or gases.
-
Avoid contact with earthed
Parts
such as
pipes, radiators cookers and refrigerators.
-
Keep children away from the working area.
-
Always wear goggles.
-
Wear a breathing mask under dusty working
conditions.
-
Store unused tools in a locked room out of
the resch of children.
-
D
O
not overload the machine.
-
D
O
not use weak tools for heavy
duty
werk.
-
D
O
not carry the machine by the power
cable.
-
Protect the power cable against heat and
sharp edges and only have it replaced by a
specialist.
-
Fasten and clamp the work piece securely.
-
Replace blunt tools.
-
Clean the machine thoroughly after use.
-
Always disconnect the power cable if the
machine is not in use, when changing tools
or case of repairs.
-
Inspect unit for darnage before use.
-
Replace defective
Parts.
-
Repairs in the electric
System
should be
carried out by a specialist.
-
Use only accessories and spare
Parts
which
ate recommended in these instructions or by
the manufacturer.
Drilling and milling machine
Overview
Legend
1.
ON
-
OFF switch with
Speed
control
(MM 40/E only)
2. Hook
3. Power cable
4.
ON
-
OFF switch (MM 40 only)
5. Locking pin
6.
Spigot nut with steel clamping jaw
7.
20 mm fitting for mounting in drill stand
Description of machine
The PROXXON drilling and milling machine
MICROMOT 40
(E)
is the ideal tool for precise
drilling, milling, grinding, polishing, brushing,
rust removal, engraving, chasing and cutting.
For hobby electronics, model making,
precision mechanics,
jewellery
shops,
opticians, arts, tool and mould making.
For marking tools and cameras.
lt
tan
be used on steel, non-ferrous metals,
glass, wood, minerals and ceramics.
The drill spindle is
supported
in a precision
ball bearing which eliminates any play.
Excellent handling because of the
pen-type grip.
The machine is reliably driven by a high torque
motor- Type 40/E is
fitted
with an
electronie
Speed
regulator.
Technical data
Length:
Weight:
Spindle collar:
Motor:
Speed (40):
Speed (40/E):
Voltage:
Power consumption:
Noise level:
approx. 220 mm
approx. 230 g
e20mm
20 000 rpm
5000 to 20 000 rpm
12to18V
approx. 40 W
5
70
dB
(A)
Accessories:
Drill chuck for Micromot machines
Power unit NG 2
(S/E)
or
NG 5 (E)
Drill stand MBS 140
Universal holder UH 34
Operation
Clamping, changing tools
Atten tionl
Disconnect mains plug before changing tools.
Never press the locking knob (arrow Fig. 2)
while the machine is running.
1. Turn the spigot nut
1
(Fig. 2) gently while
pressing the locking knob until it engages.
2. Open the clamping jaw and
Change
the
too1.
Clamp all tools as short as possible. Shafts,
which
protrude
too far will bend easily causing
the machine to vibrate.
Power supply
Use only power units with a minimum power
output of 1 A. We recommend use of the
PROXXON power units NG 2 (SE)
or
NG 5
(E).
1. Push the non-reversible plug into the power
unit.
If overloaded, the PROXXON power unit will
switch off automatically. Disconnect mains
plug and let the power unit cool down for a
few minutes.
Working with the machine
Always wear goggles.
D
O
not use any broken grinding discs
or
bent
shafts.
2. Switch the machine on
1
or
4 (Fig. 1) and
set the correct
Speed
(40/E
only) with the
button
1.
Note:
Pressing hard does not achieve good
results
when grinding. Use the correct speed and
maintain it.
Small
tools pins
=
high speed
Big tools pins
=
low
Speed
3. Fig. 3
Shows
two typical methods for
holding MICROMOT 40. When working,
ensure that the tool is held firmly in
Order
to guide the rotating
application
tool in a
controlied
manner without thereby blocking
the ventillation
Slots.
4. If the unit overheats,
switch
it off and
allow
it to cool for
a
few minutes.
The
electronie
Speed
regulation works only
with non-stabilized power units (e. g. all
PROXXON power units).
If
connected to a
battery, the unit wilf only
run
at max.
Speed.
EC declaration of
conformity
We
declare
sole
liability
for
conformity
of
this
product
with the following EC guidelines:
l
EC EMC Guideline
89L336
l
EC
Machine
Guicleline
89/392
Dipl. Ing. Martin Faßbender
PROXXON S.A.
Equipment Safety
Dept.
-6-
-7-
