Technical data
Voltage: 12 to 18 V
Power consumption: 40 Watt
Speed: 150 rpm
Gear ration 93:1
Friction clutch 5-step, 0, 25 to1, 0 Nm
Noise: ≤ 70 dB (A)
Torque with the friction clutch switched off (step 6)
2 Nm
Weight: 400g
Recommended accessories
The machine should be used with the supplied power pack
or a similar rated one with a power of min. 1 A and an
output voltage of 12 V! We recommend PROXXON power
units.
Operation
Clamping, changing tools
Warning!
Disconnect the machine from the powerpack before
changing tools.
Insert the drill chuck key 2 (Fig. 2) into the drill chuck (1)
and turn in direction "A" to open the chuck.
Insert the tool (3) into the drill chuck until it bottoms and
turn the drill chuck key in direction 'B´ to clamp the tool.
Adjusting the torque
Turn the adjustment ring 1 (Fig. 3) to the desired torque
value:
Step 1 ~ 0,35 Nm
Step 5 ~ 1,0 Nm
Step 6 ~ 2 Nm (clutch OFF)
Connecting the machine
Insert the plug (Fig. 4) into the socket on the PROXXON
power pack.
Working with the machine
Danger of injury!
Replace worn tools in due time.
Adjust the correct torque for the work on the adjustment
ring (Fig. 3).
Note:
Torques which must be strictly observed should be
determined with a torque wrench.
Attach the screwdriver to the screw or nut and hold it as
shown in Fig. 5 or 6. Operate the tumbler switch "A" or "B"
(Fig. 5 and 6)
Always clamp the tools securely.
Press A = clockwise rotation
Press B = counter-clockwise rotation
Accessories
(included): 13 burnished inserts with 3,5 mm shank
Care and maintenance
After use:
Warning!
When finished using the machine, unplug it and remove
any dust clinging to vent slits.
Clean the unit thoroughly, removing all dust with a brush or
a soft cloth. Ensure all ventilation slots are free from
obstruction.
Warning!
Turn switch OFF and always remove plug from power
source before making any adjustments or repairs.
If any part is missing or damaged, do not plug the tool in
until the missing or damaged part is replaced, and
assembly is complete. To avoid electrical shock, use only
identical replacement parts when servicing double
insulated tools.
All electrical or mechanical repairs should be done only by
qualified service technicians.
When servicing use only PROXXON replacement parts.
Use of any other parts may create a hazard or cause
product damage.
Any attempt to repair or replace electrical parts on this tool
may create a hazard unless repair is done by a qualified
service technician.
Repair service is available at your PROXXON service
center (You find the address at address at the back of this
manual).
