Manual MICROMOT Jigsaw STS 12/E
Technical Data:
General:
This very lightweight and powerful machine is ideal for
curved cuts in wood up to 3/8” (10 mm), circuit boards up to
7/64” (3 mm) and non-ferrous metals up to 3/32” (2,5 mm)
thickness. Its weight makes it easy to handle and thus allows
for precise control of the cutting action.
-
Voltage: 2 – 18 Volt
-
Direct current (DC) motor, 5 poles, current consumption
max. 100 W.
-
Electronic speed control for strokes from 2,000 –
5,000/min, stroke: 15/64” (6 mm)
-
Noise development max.70 dB (A)
Legend (fig. 1):
-
Cutting depth: in wood up to 3/8” (10 mm), in circuit-
boards up to 7/64” (3 mm), in non-ferrous metal up to
3/32” (2,5 mm).
1. speed control knob
2. plug for connection for power supply (AC adapter)
-
Housing made of fiberglass reinforced Nylon.
3. on/off switch
-
3 ¼” (100 cm) spiral cord.
4. saw table
5. piston
Note:
6. saw blade
The electronic speed-control is thyristor-regulated.
Therefore it works only, when the unit is connected to non
stabilized power supplies (e.g. all PROXXON MICROMOT
power supplies). When connecting the unit to a battery, it will
run full speed, only.
Power Supplies for Jigsaw STS 12/E:
For operating this unit we recommend PROXXON
MICROMOT power supplies NG 2/S or NG 5/E or other
power supply units with a minimum capacity of 2.0 A
(24 VA).
Fig. 1
