2Description of the machine
Thank you for purchasing the TG 125/E disc
grinding machine. Younow own ahigh-preci-
sion machine to use in grinding work for which
complete accuracy is required.
Ahigh-precision manufactured and carefully
balanced grinding disc with double ball-bearing
direct drive guarantees excellent smoothness,
precision concentricity and minimum wear.
In this way,soft and hardwoods, plates, non-
ferrous metal or steel, even plastic, cork, rubber
and many further materials can be processed
with high precision at grinding speeds of
approx. 250-800 m/min (adjustable).
The various fixing possibilities ensureparticular
flexibility: Your TG 125/E can be operated both
in "normal position" and in standing, with the
grinding table removed. To this end, it is fixed
with the enclosed clamp.
The grinding table is made of high-grade alu-
minium and can be adjusted upwards by 10°
and downwards by 50°. This also includes the
guide slot for the angle stop that is also
included in the scope of delivery.
Twogrinding wheels in each of the grain sizes
offered of 80, 150 and 240 areincluded in the
scope of delivery.
In order that the swarf goes directly whereit
should, namely into the vacuum cleaner,thereis
aconnecting piece to which the vacuum cleaner
can be connected. So you areoptimally
equipped for the grinding work.
3Scope of delivery
1x TG 125/E disc grinding machine
1x Angle stop
1x Connecting piece
1x Rubber connector
2x Grinding wheels grain 80
2x Grinding wheels grain 150
2x Grinding wheels grain 240
1x Operating instructions
1x Brochurewith safety instructions
1x Vice
4Technical data
Dimensions and weights:
Length: approx. 300 mm
Width: approx. 140 mm
Height: approx. 160 mm
Weight: approx. 3kg
ØGrinding disc: 125 mm
Dimensionsgrinding table: 98 x140 mm
Motor:
Voltage: 230 volt,
50/60 Hz
Power input: 140 watt
KB 15 min
Speed: max. 3600 rpm
Grinding speed: approx. 250-800 rpm
Noise development: <55dB(A)
Vibration: ≤ 2,5 m/ s
2
Only in dry rooms
Please do not dispose of this electrical
machine in the household refuse!
Wear safety glasses!
5Beforework
5.1 Setting up your disc grinding
machine (fig. 2):
Note:
When setting up the machine,make surethat
the ground below it is level and secure! Asecure
stand is indispensable for working with the
machine!
Note:
When setting up and fixing the machine, always
disconnect the mains plug to prevent the disc
being started up accidentally. Risk of injury!
Caution:
During all adjusting and assemblywork, such as
when adjusting the angle stop or when attach-
ing or removing the grinding table, disconnect
the mains plug to prevent the device from start-
ing up unintentionally!
-12-
