PS Engineering
PA50 Four-channel Audio Summing Amplifier
Installation and Operator’s Manual
200-150-0100 Page 1-3 October 2006
PA50 Installation Kit:
Part Number Description Quantity
425-025-0006 DB25 Female 1
200-150-0100 Operator's and Installation Manual 1
1.7 EQUIPMENT REQUIRED BUT NOT SUPPLIED
Circuit Breaker: 1 ea. 1 amp.
Input signal source, (in ex TAWS alert signal)
Aircraft audio system to accept the summed signals
Interconnect Wiring
1.8 LICENSE REQUIREMENTS
None
