PS Engineering
PMA8000 Series Audio Selector Panel and Intercom System
Installation and Operator’s Manual
200-890-0000 Page 1-4 Revision 9, June 2005
1.6 EQUIPMENT SUPPLIED
1 ea. of the following units:
Model Description Part Number
PMA8000 PMA8000 Audio Panel with Marker Beacon and Stereo intercom. 050-890-0100
PMA8000 with option 1 Add Internal recorder to PMA8000 050-890-0200
PMA8000 Installation Kit: 250-890-0000
Description Quantity Part
Number
PMA8000 installation rack assembly 1 430-890-0040
PMA8000 Rack back plate 1 430-890-0050
44-pin connector kit 2 120-891-2045-
Backshell, connector 2 625-025-2465
4 40 X 7/16 screw w/nylon patch 4 475-440-0007
4 40 X 1/4 screw w/lock washer 4 475-440-0004
4-40 Lock Nut 5 475-013-0001
Solder Lug 1 475-009-0001
Cable Clamp 1 625-001-0002
#6-32 x ½” Flat head Philips screw 6 475-632-0012
#6-32 Clip Nut 6 475-630-0002
1.7 EQUIPMENT REQUIRED BUT NOT SUPPLIED
a. Circuit Breaker: 1 ea; 5 amp PULL TYPE REQUIRED for PMA8000
a) Speaker, 4
b) Headphone Jacks (Stereo, as Required)
c) Microphone Jacks (as Required)
d) Headphones, 150 (Stereo), up to 6 as required
e) Microphones, up to 6 as required
f) Marker Antenna (75 MHz, VSWR <1:1.5, and appropriate for the airspeed)
g) Interconnect Wiring
1.8 LICENSE REQUIREMENTS
None
