PSS M Series - 3.3 LCD Control Panel

- 5 -
Side View
(1) handles (2) fixing screw hole (3) LCD Display (4) Parallel Port 1 (5) USB
port (6) Parallel Port 2 （7）COM（RS232） （8）Battery Slot (9)Output breaker
(10) Intelligent slot (11) PDU (12) EPO (13) Input breaker (14) Input terminal
(15) Output IEC (16) Output terminal
3.3 LCD control panel
123
4
5
678
LCD control panel introduction
(1) INVERTER LED
(2) BATTERY LED
(3) BYPASS LED
(4) ALARM LED
(5) LCD display
(6) UP button
(7) DOWN button
(8) ESC /OFF button
(9) ENTER/ON button
