4
1. Attach rubber hose onto the intake port of the sandblaster then attach the other end of the
black hose to the pick-up tube. Place pick-up tube in source material for blasting.
2. Attach the air compressor hose to the 1/4 in. NPT (F) plug at the air inlet on the tool.
ASSEMBLY INSTRUCTIONS
USE AND MAINTENANCE OF THE TOOL
• Make sure the tools moving parts are not aligned or blocked, that it has not broken any parts
or any other condition that may affect the operation of the tool. In case of damage, take the
tool to a repair service before using it again. Many accidents are caused by poorly maintained
tools.
• Tools used for cutting, with sharp pieces that have had good maintenance, are less likely to
become blocked and are easier to control.
• Use the tool, accessories and blades, etc. according to these instructions, taking into account
the working conditions and the work to be done. The use of the tool for operations other than
those provided can lead to dangerous situations.
Clean air of correct air pressure is recommended for the power supply for this tool. A maximum of
90 PSI at the tool is recommended for most air tools of this class. Check specifications section for
recommended pressure. (Depending on length of air hose and other circumstances, air pressure at
compressor may need to be increased to 100 PSI to ensure 90 PSI at the tool.)
Water in the air hose and compressor tank contributes to reduced performance and damage of the
air tool. Drain the air tank and filters before each use and as necessary to keep the air supply dry.
Hose length over 25’ causes loss in line pressure. Increase hose I.D. or increase compressor
pressure to compensate for the pressure loss. Use an in-line pressure regulator with gauge if air
inlet pressure is critical.
AIR SOURCE
WARNING! Oil tool before each use. 4 to 5 drops of a good grade Air Tool
Oil placed in the air inlet is sufficient. Use proper air pressure and CFM
rating listed for this tool.
LUBRICATION & MAINTENANCE
Drain water from hoses and compressor tank. Water in the air supply line will cause gumming and
loss of power. Clean the air filter on the supply line and flush the tool with gum solvent or a 50/50
mix of air tool oil and kerosene. It may be necessary to disassemble the tool to properly clean and
re-lubricate.
