PARTS LIST IMPORTANT SAFETY INFORMATION CONT.
21. Keep working parts of the tool away from hands and body.
22. Do not carry the tool by the air hose.
23. Do not apply excessive force of any kind to the tool. Let the tool perform the work at
the rate as it was designed.
24. Do not remove any labels on the tool. Replace if they become obscured or damaged.
25. Always maintain the tool with care. Keep it clean for the best and safest performance.
26. It is not recommended that quick change couplings should be located directly at the
air inlet, as they add weight and could fail due to vibration.
27. This tool vibrates with use. Continuous operation of this tool might be harmful to your
hands or arms. Stop using the tool if discomfort, a tingling feeling or pain occurs.
Resume work after recovery. Seek medical advice if a serious symptom occurs.
1. Always use the impact wrench in the manner and for the functions described in this manual.
2. Always ensure the wrench is not moving and disconnected from the air supply when
changing sockets etc. Only use impact sockets. Do not use standard sockets.
3. Always finish tightening wheel nuts or engine parts with a torque wrench or suitable
spanner to the correct torque as recommended by the vehicle manufacturer.
4. Always avoid excessive use of the impact wrench. When tightening a nut or bolt,
never allow the wrench to impact more than 8 times. This is to avoid over-tightening. 3
to 4 impacts is normally sufficient.
5. Always ensure that the socket is correctly installed onto the tool anvil before starting the tool.
6. Due to the possible presence of asbestos dust from brake linings, always wear suitable
respiratory protection.
7. Never carry the impact wrench by the air supply hose.
8. Always disconnect the tool from the air supply when changing impact sockets or when
the wrench is not required for immediate use in order to avoid accidental start.
9. Hold the tool correctly. Always use both hands to control the impact wrench.
10. Always ensure that the wrench has come to a complete stop before putting it down
after use.
11. If necessary, use clamps or proper devices to securely fix the workpiece when
installing/tightening or removing/loosening threaded fasteners on the workpiece.
12. For overhead work, wear a safety helmet.
13. Do not discard the safety instructions, give them to the operator.
14.
Always store this product in a dry and safe place out of reach of children or untrained operators.
WARNING:
Repetitive motions or exposure to vibration may be harmful to your hands
and arms.
WARNING:
The warnings, cautions, and instructions discussed in this instruction manual
cannot cover all possible conditions and situations that may occur. It must be understood by the
operator that common sense and caution are factors which cannot be built into this product, but
must be supplied by the operator. Read and understand all of the instructions provided in the
instruction manual of this product, as well as, any other tool (s) used with this product.
6
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
Spring Washer
Front Cover
O Ring
Oil Sleeve
Axis Protecting Ring
Axis
Impact Frame Fixed Pin
Hammer
Impact Frame
Housing
Bearing
Cylinder
Front Cylinder Cover
Blade
Rotor
18
19
20
22
21
23
24
25
26
27
28
29
30
31
32
33
34
Rear Cylinder Cover
Cylinder Fixed Pin
Bearing
Gasket
Seal Cover
Steel ball
E Ring
Speed Control Knob
Framework Oil Seal
Air Inlet Spring
Air Inlet
Silencing Cover
8
8
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
Quantity
Item No
Description Quantity
Item No
Description
1
1
Front Cover Seal Ring
1
O Ring
1
1
Inner Hexagon Screw
Knob Spring
Trigger
Jacket
Inclined Valve
9
12
13
14
15
19
21
22
2
1
23
24
25
26
27
28
30
31
32
33
34
17
18
16
20
29
11
10
8
7
6
5
4
3
2
1
AIR IMPACT WRENCH SAFETY
3
