VFD Driver/Controller IC PT6315
PT6315 v2.0 Page 17 Sep. 2002
RECOMMENDED SOFTWARE FLOWCHART
Note: 1. Command 1: Display Mode Commands
2. Command 2: Data Setting Commands
3. Command 3 : Address Setting Commands
4. Command 4: Display Control Commands
5. When IC power is applied for the first time, the contents of the Display RAM are not defined; thus, it
is strongly suggested that the contents of the Display RAM must be cleared during the initial setting.
Figure 17: Recommended Software Flowchart
START
SET
COMMAND 2
(Write Data)
SET
COMMAND 2
(READ KEY &
WRITE DATA
INCLUDED)
SET
COMMAND 3
END
INITIAL
SETTING
MAIN
LOOP
SET
COMMAND 3
Clear Display RAM
(See Note 5)
SET
COMMAND 1
MAIN
PROGRAM
SET
COMMAND 4
SET
COMMAND 4
(88H ~ 8FH : Display
ON)
Delay 200 ms
SET
COMMAND 1
To Next Page
