VFD Driver/Controller IC PT6315
PT6315 v2.0 Page 2 Sep. 2002
BLOCK DIAGRAM
Figure 1: PT6315 Internal Block Diagram
SG1/KS1
SG2/KS2
SG3/KS3
SG4/KS4
SG5/KS5
SG6/KS6
SG7/KS7
SG8/KS8
SG9/KS9
SG10/KS10
SG11/KS11
SG12/KS12
SG13/KS13
SG14/KS14
SG15/KS15
SG16/KS16
SG21/GR8
SG22/GR7
SG23/GR6
SG24/GR5
