PTC PT6315 - Page 26

Tel : 886-2-29162151
Fax: 886-2-29174598
VFD Driver/Controller IC PT6315
PT6315 v2.0 Page 26 Sep. 2002
44-Pin SSOP Package
Notes:
1. Dimension D do not include mold flash, protrusions or gate burrs.
2. Mold flash, protrusions or gate burrs shall not exceed 0.006 inch (0.152 mm) per side
A
A1
C
0.004
SEATING PLANE
be
D
E1
E
L
0.01INCH
GAUGE PLANE
F
c
h x 45
