IRDA-WELDER T-890 USER MANUAL
Http://www.tech168.cn
2
Infrared lamp body heating size 60 X 60 mm
Preheating chassis preheating size 245 X 260 mm
Preheating chassis temperature range 0 ℃-350 ℃
Size 316mm X 410mm X 290mm
Net weight 9.3 kg
Main parts
Welding table main body 1
Infrared lamp body 1
Portal frame 2
Power line 1
User manual(Compact disc) 1
Description of the main parts
1. Welding table main body
Preheating chassis
Portal frame
Front panel
Lamp body
Slide support
Circuit board support
Focusing knob
