Solution Recovery System
Ref.
No. Part No. Description Qty.
1 B524848 Cordset 1
2A B522421 Vacuum Motor 115 V 1
2B B522422 Vacuum Motor 220V 1
3 B932255 Spring Clip 4
4 B931257 Spring 2
5 B701385 Gasket 1
6 B970589 Float Switch Housing 1
7 B931254 Float Switch 1
8 B914709 Float Switch Actuator
9 B970586 Mounting Plate 1
10 B931227 Gasket 1
11 B931666 Float Body 1
12 B970588 Float Housing 1
13 B970581 Recover Tank 1
14 B931224 Inlet Baffle 1
15 B931228 Inlet Gasket 1
16 B524881 Tank Inlet 1
17 B525026 Inlet Hose Assembly 1
18 B931309 Hose Cap 1
19 B931312 Drain Hose 1
20 B931311 Drain Hose Clamp 1
Ref.
No. Part No. Description Qty.
21 B970585 Drain Hose Connector 1
22 B802346 Strainer Assembly 1
23 B931231 Solution Tank 1
24 B931660 Strainer 1
25 B932192 Drain Body 2
26 B932188 Washer 2
27 B701391 Gasket 2
28 B932188 Washer 2
29 B932193 Nut Drain Body 2
30 B932173 Valve Drain 1
31 B931245 Solution Tank Check Unit 1
32 B960443 Rear Strap 1
33 B931665 Back-Up Blade 1
34 B700168 Hand Knob w/Studs 2
35 B931692 Rear Blades (set of 2) 1
36 B931607 Squeegee 1
37 B931614 Front Blade 1
38 B931612 Front Strap 1
39 B960697 Squeegee Assembly 1
40 B802346 Screen Assembly 1
B931522 Solution Tank Assembly
