INSTALLATION
4. Place the Mounting Rails (ISR) (1) into the
support rail weldments. Lock the base rails
into place with the hitch pin (5) and secure
with the pin clip (8).
5. Once hitch pins and clips are secured, set
your fifth wheel in the corresponding
mounting locations and secure with 1/2"
hitch pins (not included).
