Pulsar Accolade LRF XP50 User Manual

WARNING!
Do not point the objective lens of the device at intensive sources
of light such device emitting laser radiation or the sun. This may
render the electronic components inoperative. The warranty does
not cover damage caused by improper operation.
WARNING!
The radiator cooling system (12) becomes warm during operation:
this is normal and allows an increase in the sensitivity of the
device.
8
Powering on and image setup
Open the lens cover .(13)
T device ON/OFF (1) urn the on with a short press of the button.
Adjust the interpupillary distance with the rings (6) by moving the
eyepieces farther or closer to each other.
To obtain a crisp image of the icons on the display, rotate the dioptre
adjustment ring . there is no need to rotate the s (7) Once adjusted,
dioptre adjustment ring for distance or any other conditions.
To focus on the object being observed rotate the lens focusing
ring .(8)
To set up display brightness and contrast and continuous zoom,
please refer to the MENU FUNCTIONS section. QUICK
A press and ON/OFF devicefter use, hold down the button to turn the
off.
Calibration allows levelling of the background temperature of the
microbolometer and eliminates image flaws (such as frozen image,
vertical stripes etc.).
There are three calibration modes:
manual (M), semi-automatic (SA) and automatic (А).
OPERATION
SENSOR CALIBRATION
10
9
Mode М (manual)
- Close the lens cover, press briefly the ON/OFF (1) button.
- Open the lens cover.
Mode SA (semi-automatic)
- Press briefly the ON/OFF button to calibrate.
- You do not need to close the lens cover (the sensor is closed with the
internal shutter automatically).
Mode А (automatic)
- The device calibrates by itself according to the software algorithm.
You do not need to close the lens cover (the sensor is closed with the
internal shutter automatically).
- In the automatic mode the user can calibrate the sensor with the
ON/OFF (in the SA mode) button.
10
The device allows you to quickly increase the basic magnification
(please refer to the line in the specifications table) by 2 or “Digital zoom”
4 times 2 or 4 or 8 times XP models). (XQ models) or (
To operate the discrete digital zoom, press successively the DOWN (5)
button.
The digital zoom will not be saved after the device is re-started.
QUICK MENU FUNCTIONS
11
Enter the menu with a short press of the М (3) button.
To toggle between the functions below, press successively the M
button.
Select the desired mode in the menu option “CALIBRATION”
INCREMENTAL DIGITAL ZOOM
The Quick menu allows change of basic settings such as display
brightness and contrast, smooth digital zoom.
Brightness – press briefly the UP(2)/DOWN(5) buttons to
change display brightness from 00 to 20.
Contrast – press briefly the UP/ DOWN buttons to change
display contrast from 00 to 20.

Pulsar Accolade LRF XP50 Specifications

General

Vertical field of view	9.3 °
Horizontal field of view	12.4 °
Internal storage capacity	8 GB
Detection distance (vehicles)	1800 m
Sensor type	uncooled
Sensor resolution (thermal module)	640 x 480 pixels
Wi-Fi	Yes
Product color	Black
Display diagonal	- \
Housing material	-
Operating temperature (T-T)	-20 - 50 °C
International Protection (IP) code	IPX7
Battery capacity	5000 mAh
Battery life (max)	7 h

Weight and Dimensions

Depth	130 mm
Width	164 mm
Height	64 mm
Weight	600 g
