Pulsar Axion 2 XG35 User Manual

1.
Select the Stadiametric Rangefinder function with short presses of
the MENU (4) button until the icon is selected.
2.
You will see on the display: measurement bars, icons of three reference
objects and respective distances for the three objects.
3.
Position the lower fixed bar under the object being ranged.
4.
By pressing the UP (5)/DOWN (3)buttons, move the upper horizontal
bar relative to the lower fixed bar until the object fits entirely between
the two bars. The distance to the object is automatically recalculated
as you move the upper line.
5.
Exit the rangefinder mode with a long press of the MENU (4)button or
wait 10 seconds to exit automatically.
Notes:
There are three predefined values for the reference objects: Hare - 0.3
m height, Boar - 0.7 m height, Deer - 1.7 m height.
Before it appears on the display, a measured distance value is rounded
up to 5m for larger values and rounded down to 1m for smaller values.
To select the unit of measurement (Meters or Yards), go to theGeneral
Settings
Image not found or type unknown
menu item =>Units of Measure submenu.

Pulsar Axion 2 XG35 Specifications

General

Thermal Sensitivity	<40 mK
Frame Rate	50 Hz
Objective Lens	F35/1.0
Sensor Type	Uncooled Microbolometer
Display Type	AMOLED
Built-in Memory	16 GB
Wi-Fi Channel	2.4 GHz
Protection Degree	IPX7
Operating Temperature Range	-25°C to +50°C
Power Supply	3.0 - 4.2 V
Battery Capacity	4900 mAh
Magnification	2x - 8x
Detection Range	1750 meters
Display Resolution	1024x768 pixels
Video / Photo Resolution	1024x768
Video / Photo Format	MP4 / JPG
Battery Type	Li-Ion
Sensor Resolution	384x288 pixels
