1.
Insert the battery (10) fully along the guide rail into the APS* charger slot (11).
2.
Point A on the battery and Point B on the charger should be aligned.
3.
Two batteries* can be charged at the same time – a second slot is provided for
this.
4.
Attach the microUSB plug on the USB cable (15) to the microUSB connector on the
power adapter (16). Plug the device into a 100–240V power outlet (17).
5.
Attach the second plug of the microUSB cable to the socket (12) of the charger
(11).
6.
The LED indicator (13)will light up battery charge status (see table).
7.
Wait until the battery is fully charged (LED indication (13): ).
(13) LED Indicator** Battery charge status
Battery charge from 0 to 10%.
Charger not connected to the mains
power supply
Battery charge from 0 to 10%.
Charger connected to the mains
power supply
Battery defective. Do not use the
battery!
Image not found or type unknown
Battery charge from 10 to 20%
Battery charge from 20 to 60%
Image not found or type unknownImage not found or type unknown
Battery charge from 60 to 95%
Image not found or type unknownImage not found or type unknownImage not found or type unknown
Battery completely charged. Can be
disconnected from the charger
* Available separately
**The indicator displays the current level of charge of the battery for 30 seconds
when the APS charger is not plugged in. When the power is connected, the display shows
the current status of the battery constantly, the LEDs additionally flickering to
indicate the battery charging process.
