Pulsar Helion XP38 Instruction Manual

12
11
Menu contents and description
Wi-Fi
Wi-Fi ON/OFF
Off
Off
Turn Wi-Fi on with a short press of the M (9) button.
Turn Wi-Fi off with a short press of the M (9) button.
You can also turn Wi-Fi on/off with a long press of
the UP (10) button during operation.
Mode
Selection of operating mode.
There are three automatic operating modes:
Each mode includes optimal combination of
parameters (brightness, contrast, gain etc.) to
deliver best possible image in specific viewing
conditions.
Calibration
Selection of calibration mode. There are three
calibration modes: manual (M), semi-automatic
(SA) and automatic (А).
= Enter the main menu with a long press of the M
button.
= Enter the submenu with a short press of the M
button.
= Select one of the below calibration modes with
UP (10)/ DOWN (8) buttons.
= Confirm selection with a short press of the M
button.
Enhanced contrast mode.
Perfect for viewing animals against the background
of rocks, ground in mountain areas.
Rocks
Identification
Forest
Low contrast mode
Perfect for viewing animals against a background of
vegetation.
Universal mode for various modes of observation.
Color palettes
Selection of colour palettes.
Basic image mode is “White Hot”. Menu option
"Colour palettes" allows you to select an
alternative palette.
= Enter the main menu with a long press of the M (9)
button.
= Enter the submenu with a short press of the M
button.
= Select one of the palettes below with a short press
of the UP (10)/ DOWN (8) buttons.
= Confirm selection with a short press of the M
button.
Black Hot palette (white colour corresponds to
low temperature, black colour – to high
temperature)
Hot Red
Red Monochrome
Rainbow
Ultramarine
Violet
Sepia
Switch between the palette selected in the menu
and the basic palette with a short press of the UP
(10) button.
A In automatic mode the need for calibration is based
on software algorithm. Calibration starts
automatically.
The user determines for himself the need for
calibration based on the actual image status.
Manual (silent) calibration.
Close the lens cover before calibration.
SA
M
WiFi settings
Wi-Fi setup.
This menu option allows you to set up your device
for operation in a Wi-Fi network.
This menu option allows you to set a password to
access your thermal imager from an external
device.
The password is used to connect an external device
(i.e. smartphone) to your thermal imager.
= Enter the submenu "Wi-Fi" with a short press of
the M (9) button.
= The default password “12345” appears on the
display.
= Set the desired password with the UP (10) and
DOWN (8) buttons (button UP to increase value;
button DOWN to reduce). Switch between digits
with a short press of the M button.
= Save the password and exit the submenu with a
long press of the M button.
Password
setup
12345
Access
level setup
Owner
Guest
Access level setup
This menu option allows you to set required access
level of the Stream Vision application to your
device.
