Remove the protective cover from the Battery Pack.
Lift the lever (13).
Install the battery into the dedicated slot on the device housing so that
element F (Pic.2 on the flyleaf) appears from below.
Fix the battery by clicking the lever.
INSTALLATION:
Only use the charger supplied with the Battery Pack. The use of any
other charger may irreparably damage the Battery Pack or the
charger and may cause fire.
When keeping the battery for a long period, the battery should
not be fully charged or fully discharged.
Do not charge the battery immediately after bringing the
battery from cold environment to a warm one. Wait for 30-40
minutes for the battery to get warm.
Do not leave a battery unattended while charging.
Never use a modified or damaged charger.
Charge the Battery Pack at a temperature from 0 °C to +45 °C.
Otherwise batter's life will decrease significantly.
Do not leave the Battery Pack with a charger connected to the
mains longer than 24 hours after full charge.
Do not expose the battery pack to high temperature or to a naked
flame.
Do not submerge the battery in water.
Do not connect external device with a current consumption that
exceeds permitted levels.
The Battery Pack is short circuit protected. However, any situation
that may cause short-circuiting should be avoided.
Do not dismantle or deform the Battery Pack.
Do not drop or hit the battery.
When using the battery at negative temperatures, battery's capacity
decreases, this is normal and is not a defect.
Do not use the battery at the temperatures above those shown in
the table – this may decrease battery's life.
Keep the battery out of the reach of children.
SAFETY MEASURES:
EXTERNAL POWER SUPPLY
7
The device can be powered with an external power supply such as Power
Bank (5V).
Connect the external power supply to the USB port (4) of the device
(Pic. 1 on the flyleaf).
The device switches to operation from external power supply, and the
IPS5 Battery Pack will begin slowly charging.
The display will show the battery icon with charge level as a
percentage.
If the device operates on external power supply but the IPS5 battery is
not connected, the icon is shown.
When the external power supply is disconnected, the device switches
to the internal battery pack without powering off.
OPERATION
WARNING! Do not point the objective lens of the unit at intensive
sources of light such device emitting laser radiation or the sun. This
may render the electronic components inoperative. The warranty
does not cover damage caused by improper operation.
WARNING! The radiator cooling system (14) becomes warm during
operation: this is normal and allows an increase in the sensitivity of
the device.
8
Powering on and image setup
Open the lens cover (1).
Turn the unit on with a short press of the ON (11) button .
To obtain a crisp image of the icons on the display, rotate the dioptre
adjustment ring (6). After this there is no need to rotate the dioptre
adjustment ring for distance or any other conditions.
To focus on the object being observed rotate the lens focusing ring (2).
To set up display brightness and contrast and continuous zoom,
please refer to the QUICK MENU FUNCTIONS section.
After use, hold down the ON button to turn the unit off.
SENSOR CALIBRATION
9
Calibration allows levelling of the background temperature of the
microbolometer and eliminates image flaws (such as frozen image,
vertical stripes etc.).
There are three calibration modes: manual (M), semi-automatic (SA) and
automatic (А).
Select the desired mode in the menu option “CALIBRATION” .
