STEP 3 (OPTIONAL UPGRADE - SKIP TO STEP 4)
VIKI2 LCD SCREEN INSTALLATION
Make sure the Pulse is powered off before proceeding.
PLUG IN 12-PIN CONNECTOR
The black wire goes to the pin marked "GND". (A)
The red wire goes to the pin marked "+Vin". (A)
PLUG IN 4-PIN CONNECTOR
Blue wire goes to pin marked "BTN". (B)
SNAP VIKI INTO PLACE
Snap into place as shown. (C)
Turn the Pulse on and check that the screen powers on
and displays the printer status.
