Owner’s Manual High Voltage Batteries 44
Battery Installation
When working with batteries, do not put anything,
especially metal objects, across the battery terminals.
Carefully place battery cables and hold-downs making
sure that cables do not lay across vent caps.
Always remove the negative (-) cable to the motor
controller first, and install it last. A spark can occur causing
an explosion or fire at the battery.
1
2 3 4 5
6
1
2 3 4 5
6
8 7
6 BATTERY CONFIGURATION
8 BATTERY CONFIGURATION
* Will only be installed on larger carts
1
2 3 4 5
6
1
2 3 4 5
6
8 7
6 BATTERY CONFIGURATION
8 BATTERY CONFIGURATION
* Will only be installed on larger carts
1
2 3 4 5
6
1
2 3 4 5
6
8 7
6 BATTERY CONFIGURATION
8 BATTERY CONFIGURATION
* Will only be installed on larger carts
Battery cables diagram
Battery Preparations
To Next Page
