Puregas PHF - Section 6: Troubleshooting Information; Troubleshooting Matrix Overview

Page 18 of 24
FIGURE 12: REPLACEMENT PARTS FOR PCR MODEL
REPLACEMENT PARTS MODEL SIZE PART NUMBER
Desiccant Tower
PCR-15B 15", Black P010764-F1B
PCR-15W 15", White P010764-F1W
PCR-SBX 15", Black, CO2 P010764-F2B
PCR-SWX 15", White, CO2 P010764-F2W
PCR-25B 19", Black P010764-F3B
PCR-25W 19", White P010764-F3W
PCR-MBX 19", Black, CO2 P010764-F4B
PCR-MWX 19", White, CO2 P010764-F4W
PCR-50B 25", Black P010764-F5B
PCR-50W 25", White P010764-F5W
Solid State Timer
PCR-xxx-x
A
110 VAC P09740
PCR-xxx-x
B
220 VAC P09783
PCR-xxx-x
C
24 VAC P010762
PCR-xxx-x
D
12-24 VDC P010670
Solenoid Valve PCR-xxx-
1
A
110 VAC P010679F1
PCR-xxx-
2B
220 VAC P010679F2
PCR-xxx-
3D
12 VDC P010679F3
PCR-xxx-
4D
24 VDC P010679F4
PCR-xxx-
5C
24 VAC P010679F5
Shuttle Valve
Inlet (all models) n/a P010652
Outlet with gauge option Specify Orifice ### P010652, ###
Outlet without gauge option Specify Orifice ### P010509, ###
Outlet shuttle disk Specify Orifice ### P09881F###
Inlet shuttle disk n/a P09881F000
Purge Muffler
All models n/a P010734F2
Tower Pressure Gauge PCR
G
n/a P010733
ACCESSORIES FOR PCR MODELS
Inlet 5-micron Particulate Filter
1/2" NPT 5-micron P010547
Replacement Element for P010547
P010554
Inlet Carbon Filter
1/2" NPT Carbon P010976F3
Replacement Element for P010976F3
P010657
Inlet 0.01-micron Coalescing Filter
1/2" NPT 0.01-micron P010549
Replacement Element for P010549
P010556
Outlet 5-micron Particulate Filter
1/2" NPT 5-micron P010683
Replacement Element for P010683
P010554
Moisture Indicator Kit
1/2" NPT P010103
Flow meter with Throttle Control Valve
2 - 20 cfm 1/2" NPT P011047F14
3 - 30 cfm 1/2" NPT P011047F15
4 - 50 cfm 1/2" or 1" NPT P011047F16
Electronic Humidity Alarm
110 VAC 5-15% Humidity P010124-G1
220 VAC 5-15% Humidity P010124-G2
110 VAC 1.6-6% Humidity P010124-G3
220 VAC 1.6-6% Humidity P010124-G4
