Puregas PHF - Figure 14: Replacement Parts for Pmd and Toc Models

Page 20 of 24
FIGURE 14: REPLACEMENT PARTS FOR PMD AND TOC MODELS
REPLACEMENT PARTS MODEL SIZE PART NUMBER
Dryer Maintenance Kit**
PMD-
S
n/a P010845F1
**Includes desiccant chambers (2), tubing & fittings.
PMD-
S
X
(TOC)
n/a P010845F2
PMD-
M
n/a P010845F3
PMD-
MX
n/a P010845F4
PMD-
L
n/a P010845F5
PMD-
LX
n/a P010845F6
Solid State Time
r
PMD-xx-
1
A
110 VAC P010601F1
PMD-xx-
2
B
220 VAC P010601F2
PMD-xx-
3
C/D
12-24 VDC P010567
4-Way Valve PMD-xx-1
A
110 VAC P010605
PMD-xx-2
B
220 VAC P010606
PMD-xx-3
C
12 VDC P010609
PMD-xx-3
D
24 VDC P010604
Shuttle Valve
All models Specify Orifice ## P010577, ##
ACCESSORIES FOR PMD and TOC MODELS
Inlet 5-micron Particulate Filter
1/8" NPT 5-micron P010614
Replacement Element for P010614
P010615
Inlet Carbon Filter
1/8" NPT Carbon P010976F1
Replacement Element for P010976F1
P010668
Inlet 0.01-micron Coalescing Filter
1/8" NPT 0.01-micron P010616
Replacement Element for P010616
P010617
Outlet 5-micron Filter-Regulator
1/8" NPT 5-micron P010684
Replacement Element for P010684
P010615
Flowmeter with Throttle Control Valve
2 - 25 lpm 1/8" NPT P011047F6
10 - 100 lpm 1/8" NPT P011047F8
0.3 - 3 scfm 1/8" NPT P011047F10
Surge Tank, 6.5 lite
r
6" diameter x 14" length P07994
