PureLink MAX2 Series - DisplayPort Output Card - MAX2-DOS100

MAX2 4K60 Cross Platform Matrix Router
27
DisplayPort Output Card - MAX2-DOS100
Number of Port
4 DisplayPort ports, 4 audio out ports
Connector Type
Female HDMI connector,
Female phoenix stereo jack
Signal Type
RGB digital Video (DVI and HDMI standards) or
YCbCr digital component Video (HDMI)
Digital Audio
Dolby Digital® Plus, Dolby® TrueHD, DTS-HD
High Res, DTS-HD Master Audio™, up to 8ch
PCM
Audio Extraction
Via 3.5mm stereo Audio out ports
Maximum Data Rate
3.4 Gbps per color (R,G,B)
Maximum Pixel Clock
300 MHz
Standard
HDMI 2.0b
Switching Speed
Max 200ns
Output Reclocking
Automatic
Output Peripheral Device Power
600 mA per Output
Output Equalization
Automatic, Max 30 m 1920 x1200 @50/60Hz
or 1080p; 8 bit color, Ultra HD 4K
Resolution
Up to Ultra HD 4K
4096z2160 4:4:4 @60Hz
HDCP Compatible
HDCP version 2.2
Support Hot Plug Detection
Yes
Single Card Weight
0.5 lbs (0.23 kg)
