PureLink MAX2 Series - HDBaseT 3.0 Output Card - MAX2-COS100

MAX2 4K60 Cross Platform Matrix Router
28
HDBaseT 3.0 Output Card - MAX2-COS100
Number of Port
4 HDBaseT ports,
4 Audio out ports
Connector Type
Female RJ45 connector,
Female phoenix stereo jack
Supported Twisted Cable Type
CAT5/5e, CAT6/6e, CAT6a, CAT7
Digital Audio
Supported when HDMI signal source used
Audio Extraction
Via phoenix stereo Audio out ports
Supported Twisted Pair Cable
Length
330 ft (100m) ; 1080p, 1920x1200 @50/60Hz, Ultra HD 4K
P. O. E M a xi m um O ut p u t Wa t t
Max 9.6Watt per channel
Resolution
Up to Ultra HD 4K
4096z2160 4:4:4 @60Hz
Maximum Data Rate
3.4 Gbps per color (R,G,B)
Switching Speed
Max 200ns
HDCP Compatible
HDCP version 2.2
Compatible Extenders
MAX2-CTR100
Single Card Weight
1 lbs (0.45 kg)
