PureLink MAX2 Series User Manual

MAX2 4K60 Cross Platform Matrix Router
36
1LC Fiber Receiver - MAX2-FR100
Connector Types
(1) 1LC Fiber output port
(1) Female HDMI port
(1) 3-pin phoenix for audio extraction
(1) 3-pin Phoenix for ES-232
Signal Type
Fiber w/Adaptive Singlemode & Multimode processing
Digital Audio Formats
Dolby Digital®, Dolby Digital EX, Dolby Digital Plus,
Dolby® TrueHD, DTS®, DTS-ES, DTS 96/24, DTS-HD
High Res, DTS-HD Master Audio™, LPCM up to 8
channels
Maximum Data Rate
18 Gbps
Operating Distance
multimode 300m, Singlemode 2Km
Compliance
HDCP 2.2
Maximum Resolution
up to Ultra HD/4K (4096x2160, 4:4:4 @ 50/60Hz)
Nominal Peak Wavelength
1550nm, 1310nm
Maximum Receiver Sensitivity
Singlemode -15dbm, multimode -16dbm
