PureLink MAX2 Series User Manual

MAX2 4K60 Cross Platform Matrix Router
37
POE Injector Specifications
POE Injector - MAX2-POE-PSU
Voltage Per output
48V
INPUT VOLTAGE RANGE
90 - 264 Vac; 127 - 350 Vdc
NUMBER OF OUTPUTS
UP TO 16 ( Module )
REGULATION
±2%
RIPPLE
480mV
MAX CONTINUOUS LOAD ( FREE AIR )
8.3 A
MAX PEAK LOAD ( FREE AIR )
13.5A
MAX CONTINUOUS LOAD (FORCED AIR )
13.5A
MAX. PEAK LOAD (FORCED AIR )
15.6A
Operating temperature
-20 °C to +80 °C (derate at 50 °C), startup at -40 °C
Operating humidity
5% to 95% (non-condensing)
Dimension & Weight
12 ⅝” X 9 ⅜” X 3.5” / 10Lbs

PureLink MAX2 Series Specifications

General

Brand	PureLink
Model	MAX2 Series
Category	Network Router
Language	English
