PureLink MAX2 Series User Manual

MAX2 4K60 Cross Platform Matrix Router
7
Rear View:
The input and output card section, MCU card (which includes communication
ports and Dante™ ports, fan blade, and power supplies are found on the rear
panel. Actual rear view will vary depending on the configuration of input and
output cards that you choose to populate in the frame.
Figure 1-2 Rear view of MAX2-20 Enclosure
➀
Input Card Section
➁
Output Card Section
➂
Main MCU Card
➃
Airlift Fan Blade
➄
Standard Redundant Power Module
➅
Standard Redundant Power Module
1
2
3
4
5
6

PureLink MAX2 Series Specifications

General

Brand	PureLink
Model	MAX2 Series
Category	Network Router
Language	English
