PureLink MAX2 Series User Manual

MAX2 4K60 Cross Platform Matrix Router
70
▪
Input Test Pattern Command :
☞ *255ITIxxxMxx!+0x0D : Command code
☞ *255ITIxxx-xxxMxx!+0x0D : Command code
☞ *255ITIxxxIxxxMxx!+0x0D : Command code
•
Ixxx : Input number
•
Mxx : Test Pattern (M00 : OFF)
Examples ():
Command Codes
Action
*255ITI001M01! 8
Input 1 test pattern Mode 1
*255ITI002M00! 8
Input 2 test pattern Mode OFF
*255ITI002I005M02! 8
Input 2,5 test pattern Mode 2
▣
Output Config Command
*255OF : Output infomation
*255OS : Output HDMI, SDI Scaler Timing
*255OV : Output Video Stream Set
*255OT : Output Test Pattern Set
*255OG : Output Scaler Color Set
*255OA : Output Audio Set
*255OP : Output RS232+ Set
*255OQ : Output Quadview Set
*255OW : Output Wall Set
*255OB : Output Wall Bezel Set
*255OR : Output Reset Set
*255OC : Output CEC Set
▪
Output Infoamtion Check Command :
☞ *255OFOxxx!+0x0D : Command code
•
Oxxx : Output number
Examples ():
Command Codes
Action
*255OFO001! 8
Input 1 infomation check
*255OFO012! 8
Input 12 infomation check
▪
Output Port Audio Setting Command
☞ *255OAOxxxHxx!+0x0D : Command code
☞ *255OAOxxxSxx!+0x0D : Command code
