PureLink MAX2 Series User Manual

MAX2 4K60 Cross Platform Matrix Router
71
☞ *255OAOxxx-xxxHxx!+0x0D : Command code
☞ *255OAOxxxOxxxOxxxHxx!+0x0D : Command code
•
Oxxx : Output port number
•
Hxx : HDMI Tx Audio Set
(H00 : Source Audio , H01 : Dante Audio , H02 : Audio Mute)
•
Sxx : Analog Stereo Audio Set
(S00 : Source Audio , S01 : Dante Audio , S02 : Audio Mute)
Examples ():
Command Codes
Action
*255OAO001H01! 8
Set HDMI output 1 audio selection to
dante audio
*255OAO001S02! 8
Set stereo output 1,3 audio selection
to mute
*255OAO001O004H02!8
Set HDMI output 1,4 audio selection
to mute
▪
Output Port Wall Mode Setting Command:
☞ *255OWOxxx-xxxMxxHxxVxxOxxxOxxxOxxxOxxx!+0x0D : Command code
☞ Oxxx-xxx : Wall mode display all output number
•
Mxx : Wall mode timing set (Mxx=00 : Wall mode off , Mxx>00 : Wall mode
on)
M00: Wall mode off
M01: 720x480p@60 Wall mode on
M02: 720x576p@50 Wall mode on
M03: 1280x720p@29 Wall mode on
M04: 1280x720p@50 Wall mode on
M05: 1280x720p@59 Wall mode on
M06: 1280x720p@60 Wall mode on
M07: 1920x1080p@29 Wall mode on
M08: 1920x1080p@50 Wall mode on
M09: 1920x1080p@59 Wall mode on
M10: 1920x1080p@60 Wall mode on
M11: 3840x2160p@29 Wall mode on
M12: 3840x2160p@50 Wall mode on
M13: 3840x2160p@59 Wall mode on
M14: 3840x2160p@60 Wall mode on
M15: 1024x768p@60 Wall mode on
M16: 1280x1024p@60 Wall mode on
M17: 1920x1200p@60 Wall mode on
•
Hxx : Horizontal layer division
•
Vxx : Vertical layer division
•
Oxxx : Wall layer output number
