PureLink MAX2 Series User Manual

MAX2 4K60 Cross Platform Matrix Router
74
Examples ():
Command Codes
Action
*255OQO001M13L05! 8
Set the quadview output 1~4 (Timing
3840x2160@59)
▪
Output Port Scaler Timing Setting Command
☞ *255OSOxxxHxx!+0x0D : Command code
☞ *255OSOxxx-xxxHxx!+0x0D : Command code
☞ *255OSOxxxOxxxOxxxHxx!+0x0D : Command code
•
Oxxx : Output port number
•
Hxx: HDMI output timing set
H00: AUTO
H01: 720x480p@60
H02: 720x576p@50
H03: 1280x720p@29
H04: 1280x720p@50
H05: 1280x720p@59
H06: 1280x720p@60
H07: 1920x1080p@29
H08: 1920x1080p@50
H09: 1920x1080p@59
H10: 1920x1080p@60
H11: 3840x2160p@29
H12: 3840x2160p@50
H13: 3840x2160p@59
H14: 3840x2160p@60
H15: 1024x768p@60
H16: 1280x1024p@60
H17: 1920x1200p@60
•
Sxx: SDI output timing set
S00: AUTO
S01: 720x480p@60
S02: 720x576p@50
S03: 1280x720p@29
S04: 1280x720p@50
S05: 1280x720p@59
S06: 1280x720p@60
S07: 1920x1080p@29
S08: 1920x1080p@50
S09: 1920x1080p@59
