PureLink MAX2 Series User Manual

MAX2 4K60 Cross Platform Matrix Router
75
S10: 1920x1080p@60
S11: 3840x2160p@29
S12: 3840x2160p@50
S13: 3840x2160p@59
S14: 3840x2160p@60
S15: 1024x768p@60
S16: 1280x1024p@60
S17: 1920x1200p@60
Examples ():
Command Codes
Action
*255OSO001H01! 8
Output 1 HDMI scaler 720x480p@60
*255OSO001-004H02! 8
Output 1-4 HDMI scaler 720x576p@50
*255OSO001O004H05!8
Output 1,4 HDMI scaler
1280x720p@59
▪
Output Scaler Stream Setting Command
☞ *255OVOxxxMxx!+0x0D : Command code
☞ *255OVOxxx-xxxMxx!+0x0D : Command code
☞ *255OVOxxxIxxxMxx!+0x0D : Command code
•
Oxxx : Output port number
•
Mxx : Video Stream Set
(M00 : Normal , M01 : Freeze , M02 : Black , M03 : Output disable)
Examples ():
Command Codes
Action
*255OVO001M01! 8
Set output 1 to video stream set freeze
*255OVO001-004M01! 8
Set output 1-4 to video stream set
freeze
*255OVO001O002M02!8
Set output 1,2 to video stream set
Black
▪
OUT Test Pattern:
☞ *255OTOxxxMxx!+0x0D : Command code
☞ *255OTOxxx-xxxMxx!+0x0D : Command code
☞ *255OTOxxxIxxxMxx!+0x0D : Command code
•
Oxxx : Output number
•
Mxx : Test Pattern (M00 : OFF)
*255OTO002M00! 8
Output port 2 Test pattern off
*255OTO001-004M02! 8
Output port 1-4 Test pattern mode 2
