PureLink MAX2 Series User Manual

MAX2 4K60 Cross Platform Matrix Router
76
▪
Output Graphic Setting Command
☞ *255OGOxxxBxxx!+0x0D : Command code
☞ *255OGOxxx-xxxSxxx!+0x0D : Command code
☞ *255OGOxxxOxxxSxxx!+0x0D : Command code
•
Oxxx : Output port number
•
Bxxx : Brightness Set (0~255 , Default : 128)
•
Hxxx : Hue Set(0~255 , Default : 128)
•
Sxxx : Saturation Set (0~255 , Default : 128)
•
Cxxx : Contrast Set(0~255 , Default : 128)
Examples ():
Command Codes
Action
*255OGO001C128! 8
Output 1 Graphic change contrast to
128
▪
Output CEC Setting Command
☞ *255OCOxxxMxx+0x0D : Command code
☞ *255OCOxxx-xxxS"xxxx"+0x0D : Command code
☞ *255OCOxxxOxxxMxx+0x0D : Command code
☞ *255OCOxxxOxxxS"xxxx"+0x0D : Command code
•
Oxxx : Output port number
•
M00 : Power OFF
•
M01 : Power ON
•
S"xxxxxxxxxx" : CEC Stream Set
Examples ():
Command Codes
Action
*255OCO001S"FE8210F0"! 8
Set output 1 CEC stream ”FE8210F0”
*255OCO001-
004S"FE8210F0"!
8
Set output 1-4 CEC
stream ”FE8210F0”
*255OCO001-004M01!8
Set Output 1-4 Power ON
▪
Output RS232+ Set:
☞ *255OPOxxxBxx,Dxx,Pxx,Sxx!+0x0D : Port Open Command code
☞ *255OPOxxx-xxxBxx,Dxx,Pxx,Sxx!+0x0D : Port Open Command code
•
Oxxx : Output port number [O000 : All output]
•
Baudrate : B00(4800) , B01(9600) , B02(19200) , B03(38400) ,
B04(57600) , B05(115200)
•
Databits : D00(7bit) , D01(8bit)
•
Parity : P00(None) , P01(Even) , P02(Odd)
•
Stopbit : S00(1bit) , S01(2Bit)
☞ *255OPCOxxx!+0x0D : Port Close Command code
