PureLink MAX2 Series User Manual

MAX2 4K60 Cross Platform Matrix Router
77
☞ *255OPCOxxx-xxx!+0x0D : Port Close Command code
•
Oxxx : Output port number [O000 : All output]
☞ *255OPOxxx"xxxxxx"!+0x0D : Data Stream Command code
•
Oxxx : Output port number [O000 : All output]
Examples ():
Command Codes
Action
*255OPO001B02,D01,P00,S00!
8
Send command to the device that is
connected to Output #1 extender
at 19200bps , 8bit , None , 1bit Set
*255OPO001-004
B01,D01,P00,S00! 8
Send command to the device that is
connected to Output 1~4 extender
at 9600bps , 8bit , None , 1bit Set
*255OPO000 “abcdefg” !8
Send to all Output open port
(abcdefg)
*255OPO001”abcdefg”! 8
Send to Output open port #1
(abcdefg)
*255OPO001-004”abcdefg” !8
Send to Output open port #1 ~ #4
(abcdefg)
▪
LAN Data Setting Command
☞ *255SNIPxxx.xxx.xxx.xxx!+0x0D : Command code
☞ *255SNSMxxx.xxx.xxx.xxx!+0x0D : Command code
☞ *255SNGWxxx.xxx.xxx.xxx!+0x0D : Command code
☞ *255SNMAxxx.xxx.xxx.xxx.xxx.xxx!+0x0D : Command code
*255SNIP192.168.000.004! 8
Set IP address at
125.135.199.004
*255SNSM255.255.255.000! 8
Set Subnet Mask at
255.255.255.000
*255SNGW192.168.000.001! 8
Set Gate Way at
192.168.000.001
*255SNMA000.001.250.128.156.005!
8
Set Mac Address at
00.01.FA.80.9C.05
▪
RS232 Setting Command
☞ *255SRBRxx!+0x0D : Baudrate Command code
•
R01 : 9600 , R02 : 19200 , R03 : 38400 , R04 : 57600 , R05 : 115200
▪
Product ID Setting Command
☞ *255SIDxxx!+0x0D : Baudrate Command code
