MAX2 4K60 Cross Platform Matrix Router
80
HTTP Protocol with LAN(TCP/IP)
Control PC Search
Searching data for channel configuration
Character train should begin with “LCD.CGI” to “O01=I08” to Output 01 = Input
8. The sequence and size of the character train must be the same.
To RESET the Protocol, a new connection to the server (Switcher) must be
established.
Switching Channels
http://192.168.0.2/LCD.CGI?O01=I01&O02=I02&O03=I03&O04=I04&O05=I
05&O06=I06
&O07=I07&O08=I08&Submit_=SEND
RESET
http://192.168.0.2/LCD.CGI?O01=I01&O02=I02&O03=I03&O04=I04&O05=I
05&O06=I06
&O07=I07&O08=I08&Submit_=RESET
Router ID verification command
code
Send “ *999I000! ”
Router will send response:
“ *255sI Router ID 255”
