Product Introduction
Thanks for choosing the HDMI 2.0 1x4 Splitter, which can distribute one HDMI input
to four outputs. The splitter supports HDMI video resolution up to 4K@60Hz 4:4:4,
1080P 3D, and multichannel audio formats. Besides passing EDID information from
the display, there are multiple built-in EDID settings can be selected by the 4-pin
DIP switch on the front panel. Moreover, the splitter supports convenient firmware
upgrade through Micro-USB port.
Features
Supports HDMI 2.0 and the video resolution up to 4K@60Hz 4:4:4.
HDMI input supports HDCP 2.2 and the outputs support HDCP Active or HDCP
Passive mode.
Supports video resolution down-scaling, the 4K input can be automatically
degraded to 1080P output for compatibility with 1080P display.
18Gbps high bandwidth.
Advanced EDID management: multiple built-in EDID settings can be selected.
Built-in equalizer for signal enhancement to avoid signal attenuation in
transmission.
Supports CEC pass-through.
Provides LEDs to indicate the current operating status.
Firmware upgrade by Micro-USB port.
Packing List
1x HDMI 2.0 1x4 Splitter
1x Power Adapter (5V DC 1A)
Note: Please contact your distributor immediately if any damage or defect in the
components is found.
